Tungsten Carbide Plates
100% virgin material HIP tungsten carbide blocks,tungsten carbide plates,tungsten carbide strips
The tungsten carbide strip has the characteristics of high red hardness, good weldability, high hardness and high wear resistance. It is mainly used in the production of solid wood, MDF, gray cast iron, non-ferrous materials, chilled cast iron, hardened steel, PCB, brake material. When using, select the appropriate material of the carbide strip according to the purpose.
STB
| TYPE | T (mm) |
W (mm) |
L (mm) |
TYPE | T (mm) |
W (mm) |
L (mm) |
|
| STB 12 | 0.8 | 1.6 | 25.4 | STB 410A | 3.2 | 7.9 | 38.1 | |
| STB 13 | 1.2 | 2.4 | 25.4 | STB 410B | 3.2 | 7.9 | 76.2 | |
| STB 13A | 1.2 | 2.4 | 20.6 | STB 412A | 3.2 | 9.5 | 50.8 | |
| STB 24A | 1.6 | 3.2 | 25.4 | STB 412B | 3.2 | 9.5 | 76.2 | |
| STB 24B | 1.6 | 3.2 | 76.2 | STB 412C | 3.2 | 9.5 | 152.4 | |
| STB 24C | 1.6 | 3.2 | 31.8 | STB 412D | 3.2 | 9.5 | 152.4 | |
| STB 26A | 1.6 | 4.8 | 25.4 | STB 416 | 3.2 | 12.7 | 152.4 | |
| STB 26C | 1.6 | 4.8 | 76.2 | STB 416A | 3.2 | 12.7 | 25.4 | |
| STB 28A | 1.6 | 6.4 | 25.4 | STB 416B | 3.2 | 12.7 | 38.1 | |
| STB 28B | 1.6 | 6.4 | 31.8 | STB 416C | 3.2 | 12.7 | 76.2 | |
| STB 28D | 1.6 | 6.4 | 76.2 | STB 420 | 3.2 | 15.9 | 152.4 | |
| STB 14 | 2.0 | 3.2 | 28.6 | STB 68 | 4.8 | 6.4 | 152.4 | |
| STB 34 | 2.4 | 3.2 | 127.0 | STB 68A | 4.8 | 6.4 | 76.2 | |
| STB 36 | 2.4 | 4.8 | 28.6 | STB 610 | 4.8 | 7.9 | 152.4 | |
| STB 36A | 2.4 | 4.8 | 31.8 | STB 610A | 4.8 | 7.9 | 76.2 | |
| STB 38A | 2.4 | 6.4 | 25.4 | STB 612 | 4.8 | 9.5 | 152.4 | |
| STB 38B | 2.4 | 6.4 | 38.1 | STB 612A | 4.8 | 9.5 | 76.2 | |
| STB 38D | 2.4 | 6.4 | 127.0 | STB 616 | 4.8 | 12.7 | 152.4 | |
| STB 310A | 2.4 | 7.9 | 50.8 | STB 616A | 4.8 | 12.7 | 76.2 | |
| STB 310B | 2.4 | 7.9 | 76.2 | STB 620 | 4.8 | 15.9 | 152.4 | |
| STB 310C | 2.4 | 7.9 | 127.0 | STB 620A | 4.8 | 15.9 | 76.2 | |
| STB 312 | 2.4 | 9.5 | 127.0 | STB 812 | 6.4 | 9.5 | 152.4 | |
| STB 46 | 3.2 | 4.8 | 152.4 | STB 812A | 6.4 | 9.5 | 76.2 | |
| STB 48A | 3.2 | 6.4 | 25.4 | STB 816 | 6.4 | 12.7 | 152.4 | |
| STB 48B | 3.2 | 6.4 | 31.8 | STB 816A | 6.4 | 12.7 | 76.2 | |
| STB 48C | 3.2 | 6.4 | 57.2 | STB 820 | 6.4 | 15.9 | 152.4 | |
| STB 48D | 3.2 | 6.4 | 76.2 | STB 820A | 6.4 | 15.9 | 76.2 | |
| STB 48E | 3.2 | 6.4 | 152.4 | STB 824 | 6.4 | 19.1 | 152.4 | |
| STB 410 | 3.2 | 6.4 | 152.4 | STB 824A | 6.4 | 19.1 | 76.2 |
