Tungsten Carbide Rods h6

Solid Tungsten carbide rod is mainly applied in making drills, end mills,screw tap and reamers. And it is also used for cutting, punching and measuring tools. It is used in the industries of paper making, package, printing, non-ferrous metal processing. Also, it’s an excellent material to processe as HSS cutting tool and holemaking tools,wear-resistant parts,shanks for drill bits and etc.

Send Inquiry

Tungsten Carbide Rods With Tolerance H6, h6, H5, h5, H7, h7

Application:

Used in welding/ making the drill bits/ endmills / reamers .automobile special cutters, printed circuit board special cutters, engine special cutters, Horologe processing special cutters, integral vertical milling cutter, graver and etc. Besides, they can bu used for making of cemented carbide stamping head, Core bar and perforation tools.

The Specification Range of extruded Grounded Tungsten Carbide Rod :

WC Grain size range: 0.3~0.5μ.m; 0.5~0.9μ.m; 1.0~1.3μ.m; 1.4~2.0μ.m.
Length range:3mm-600mm; (General Length: 100mm,300mm,320mm,330mm)
Diameter Grade: h4(H4), h5(H5), h6(H6), h7(H7), h8(H8), h9(H9), etc.

Good grinding machine to ensure the sphencity & the Linearity of rod at higher level standard;
Sphericity tolerance range: 0.001mm ~ 0.005mm;
Linearity tolerance range: 0.001mm~0.1mm;
Surface Roughness can be reached to: RA0.04.(reach a mirror effect surface after fine grinding)
